UV-PH Positive UV-CTP Plate
Huaguang UV-PH positive UV-CTP plate is a kind of high quality UV-CTP plate developed by Lucky Huaguang Graphics Co.Ltd for customers, which makes the printing enterprise in the production of both economic efficiency at the same time. It is widely used in sheet-fed and web commercial press.
Contact usHuaguang UV-PH positive UV-CTP plate is a kind of high quality UV-CTP plate developed by Lucky Huaguang Graphics Co.Ltd for customers, which makes the printing enterprise in the production of both economic efficiency at the same time. It is widely used in sheet-fed and web commercial press.
Specially designed for UV Technology
Huaguang UV-PH positive UV-CTP plate is a UV-CTP plate developed to meet the market requirements for plate-making speed and efficiency. Specifically designed for the CTcP technology, the features of UV-PH is the new UV photosensitive layer formula and high quality electrolytic oxidation of the aluminum substrate.
Excellent printing performance
With new photosensitive layer fomula and high-quality substrate treatment technology, the plate has precisely dot reduction, excellent ink balance performance and superior wear resistance. The run length is up to 150, 000 impressions without baking. It can also be used in UV-ink printing after baking.
High-quality image performance
Huaguang UV-PH positive UV-CTP plate possesses high resolution and it can achieve 2 to 98% @ 250lpi AM screening resolution and 25 micron FM screening resolution .
Excellent stability and adaptability
Huaguang UV-PH positive UV-CTP plate has good storage stability, its sensitivity, dot reduction and other properties are almost unchanged in the shelf life.
With good development adaptability, Huaguang UV-PH positive UV-CTP is suitable for the mainstream UV-CTP platesetters.
Plate Type | Positive UV-CTP plate |
Gauge | 0.15/0.20/0.25/0.30/0.40mm |
Substrate | Electronically grained and anodized aluminum substrate |
Application | commercial sheetfed and rotary press printing. |
Spectral sensitivity | 350-460mm UV light, especially 400-410mm UV laser. |
Platesetter | Compatible with mainstream UV-CTP platesetters in the market. |
Exposure energy | 30-35mW（Cron UV-4632CI type platesetter , parameters 1000 rpm.） |
Resolution | 2-98%@250lpi（Platesetters in different resolution will have difference).） |
Processor | Compatible with mainstream processors in the market |
developer Dynamic replenishment | Huaguang PD positive PS plate developer are recommended.
24±1℃ 20-30 seconds 100-150ml/m2 |
Safelights | yellow light handing |
Working conditions | Operating temperature 21-25 ℃ (room temperature), relative humidity 40-60% |
Storage condition | Storage temperature: 15-27℃, relative humidity: 25-60%, shelf life：18 months under recommended storage condition |
Run length | Up to 150,000 impressions without baking. Actual run length will have differences according to press/paper/ink/chemicals conditions |
